Explosion-protected Spot Cooler
<h6″>CFC and HCFC FreeTechnology Institution of Industrial Safety certified product
Countermeasure for heat stroke in hazardous areas.
Features
[1] Can be used in Zone 1 and Zone 2 hazardous areas.
Note: See classification of explosive gas and electrical equipment.
[2] Refrigerant circuits are pressurized enclosures, while the control circuits are flameproof enclosures.
[3] The entire unit is of an explosion-protected construction.
[4] A drain tank has been installed at the bottom of the unit.
[5] The length of the power cord can be changed (optional, standard length: 3m).
[6] Comes with wheels and stoppers to make moving and anchoring the unit convenient.
Product Specifications
| Model | DGR-1A-SP | DGR-1A-SPS |
|---|---|---|
| Certification number | #T59062 | |
| External dimensions[mm] | W730 D700(+140) H1144 | W800 D800(+110) H1359 |
| Material | Interior and exterior: SUS304 stainless steel |
|
| Ventilation | Propeller fan | Sirocco fan |
| Air flow rate | ・50Hz ~5.4m3/min ・60Hz ~6.0m3/min |
・50Hz ~10.0m3/min ・60Hz ~11.0m3/min |
| Breaker | 20A | |
| Cooling capacity | 1.4kW | |
| Explosion-proof performance | fd2G4 | |
| Power | Single-phase 100 V, 50 / 60 Hz, power cord, 3PNCT, 3.5sq, 3-core 3m, round terminal, no plug |
|
